Bosch Purion 400 display retrofit kit for Bosch smartsystem

Bosch Purion 400 display retrofit kit for Bosch smartsystem

Bosch Purion 400 display & retrofit kit

Compatible with all motors and batteries in the Bosch smart system.

Installation

Method 1

Bosch Purion 400 display with Bosch System Controller and the Bosch Mini Remote. Also required, Bosch Y display cable. The Y cable is connected to the motor, System Controller and Purion 400. The Mini Remote on the handlebar is connected to the system via Bluetooth.

Method 2

Bosch Purion 400 display with Bosch LED Remote. Also required Bosch display cable, which is available in various lengths. The display cable connects the motor to the Purion 400.

Contents

  • 1x Purion 400 display
  • 1x Bracket 31.8mm or 35mm - select correct size for handle bar (check bike spec)
  • 1x Screw M4x10.5
  • 1x Operating and installation instructions

    When retrofitting the Purion 400 with Y cable assembly, please order the blanking plug  to close the unused display port on the Purion 400 separately.

Description

  • Transmissive 1.6-inch TFT display (320 x 160 pixels)
  • IP55 protected against water splash and dust
  • Positioned in the handlebar triangle to protect the display
  • Operation via the LED Remote or Mini Remote (in conjunction with the System Controller)
  • Audible signals for navigation and system cues

Connectivity

  • Recording activities via LED Remote, System Controller and eBike Flow app
  • Remaining range overview depending on the various riding modes
  • Warnings if state of charge of the phone drops below 30%
  • Customisation of the status bar (display of state of charge, time or speed)
  • Software updates via eBike Flow app
  • Additional features: Shift recommendation, display of riding and fitness data, display when walk assistance and light are activated
